SP100 Series Solar Pump Inverter

The SP100 series solar pump inverter is specially developed by INVT for solar pump applications. With a high level of water and dust protection, it can be installed outdoors without additional protective measures. It integrates a built-in DC switch, fuse, and combiner functions, and supports both single-phase and three-phase configurations. It also supports up to 900VDC input, a hybrid power supply, and 4G/WiFi IoT modules for remote monitoring and control. It also comes with an LCD keypad, multiple sensor inputs, and dedicated solar pump features such as weak-light protection, water level protection, and flow calculation.

·0.75~22kW
·DC100-900V/AC220~380V
·IP66
  • SP100 Series Solar Pump Inverter
  • SP100 Series Solar Pump Inverter
  • SP100 Series Solar Pump Inverter
VideoVideo
ImagesImages
  • SP100 Series Solar Pump Inverter
    SP100 Series Solar Pump Inverter
  • SP100 Series Solar Pump Inverter
  • SP100 Series Solar Pump Inverter
  • SP100 Series Solar Pump Inverter
Overview
Features
Specifications
Downloads
More Resources
更多支持

Features

High integration
Built-in DC switch reduces the need for external components, reducing system costs.
Built-in fuse and combiner functions eliminate the need for an external combiner box, allowing direct connection to the inverter for a safe and hassle-free operation.
Built-in reverse cut-off diode prevents reverse current from the mains during the hybrid power supply.
01
Comprehensive protection
IP66 rating provides superior dust and water protection, enabling outdoor installation.
Features protection functions specifically designed for solar pump applications. The protection functions include weak-light alarms, dry pumping alarms, and full-/empty-water pre-alarms.
Provides standard inverter protection against output overcurrent, bus overvoltage/undervoltage, output phase loss, and overtemperature.
02
Outstanding solar pump drive
Compatible with both asynchronous motors and permanent magnet synchronous motors, supporting V/F control and sensorless vector control (SVC).
Can drive both single-phase and three-phase motors.
Supports AC/DC hybrid input, with DC input up to 900V.
Achieves an MPPT control efficiency greater than 99%.
Flow calculation function is available.
Equipped with an LCD keypad for displaying cumulative flow, cumulative electricity consumption, and running time.
03
Remote control
Optional 4G/WiFi module supports remote status monitoring, parameter configuration, and start/stop control.
04

Specifications

Item

Specifications

Input

AC input voltage (V)

4, 4-T: AC 3PH 380V (-15%) – 440V (+10%); rated voltage: 380V

2, 2-T: AC 3PH/1PH 220V (-15%) – 240V (+10%); rated voltage: 220V

PV input voltage (V)

4: DC 250V–900V

Recommended MPP voltage: 570V

D4: DC 250V–900V

Recommended MPP voltage: 570V

2: DC 150V–450V

Recommended MPP voltage: 350V

D4: DC 150V–450V

Recommended MPP voltage: 350V

4-T: DC 220V–900V

Recommended MPP voltage: 570V

2-T: DC 100V–450V

Recommended MPP voltage: 350V

Input current (A)

See the manual for product ratings.

PV max. input current (A)

See the manual for product ratings.

Input frequency (Hz)

2, 4, 2-T, and 4-T AC models: 50Hz or 60Hz; allowed range: 47–63Hz, with a maximum change rate of 20%/s

Short-circuit capacity

According to IEC 61439‑1, the rated short-time withstand current at the incoming terminals of the switchgear assembly is up to 100kA. The VFD is suitable for applications where the prospective short-circuit current does not exceed the breaking capacity (for example, 100kA) of its protective devices, and its rated operational current is significantly lower than this value—typically ≤ 1kA.

Output

Output voltage (V)

4, D4, 4-T: 0–380V

2, D2, 2-T: 0–220V

Output current (A)

See the manual for product ratings.

Output power (kW)

See the manual for product ratings.

Output frequency (Hz)

0–400Hz

Control performance

Control mode

Space voltage vector control, and sensorless vector control (SVC)

Motor

Motor type: Asynchronous motor (AM) and synchronous motor (SM)

Voltage: 0–U1 (motor rated voltage), 3PH symmetrical, Umax (VFD rated voltage) at the field-weakening point

Short-circuit protection: The motor output short-circuit protection meets the requirements of IEC 61800-5-1.

Frequency: 0–400Hz

Frequency resolution: 0.01Hz

Field-weakening point: 10–400Hz

Carrier frequency: 1–15kHz. Refer to the function code P00.14 for the default carrier frequency.

Maximum motor cable length: 200m

Speed ratio

For AMs: 1:200 (SVC)

For SMs: 1:20 (SVC)

Speed control accuracy

±0.2% (SVC)

Speed fluctuation

±0.3% (SVC)

Overload capacity

120% of rated current for 60s, and 150% of rated current for 10s

Terminal digital input resolution

No more than 2ms

Digital input

Three regular inputs; max. frequency: 1kHz

Relay output

One programmable relay output

RO1A: NO; RO1B: NC; RO1C: common

Contact capacity: 3A/AC 250V, 1A/DC 30V

Environmental requirements and standards

Mounting method

Only supports wall mounting

Temperature of running environment

-10℃–+60℃

Note: Derating is required when the ambient temperature exceeds 45°C.

Ingress protection (IP) rating

IP66

Pollution degree

Degree 2

Cooling method

Natural heat dissipation or forced air cooling
