VCA Series Inverter Large Room Precision Cooling System(25-120kW)

1. Energy efficient
● Scroll compressors that has 20%~100% dynamic adjustment of cooling capacity output.
● V-type evaporator, high heat exchange efficiency.
● High-precision electronic expansion valve, precise regulation of refrigerant flow.
● EC fan with real-time adjustment of airflow output according to demand.

2. Safe and reliable
● The main components adopt international famous brands.
 --LS circuit breaker
 --Schneider contactors
 --Standard G4 filter
 --INVT controller & VFD
--standard oil separator
● Real time monitoring of input voltage and frequency.
● Intelligent monitoring of air conditioner power supply voltage, frequency and three-phase unbalance.
● Double electric control box design, strong and weak electrical isolation to avoid signal disturbance.
● Fan & drive integration of indoor unit.
● Separate outdoor unit’s switch & VFD.

3. Intelligent control
● Standard 10-inch color capacitive touch screen.
● Standard RS485 interface, optional SNMP interface.
● Support temperature and humidity curve display and graphic status display.
● More than 2000 historical alarm information storage.
● Use CAN communication to do network group control.

4. Flexible configuration
● Optional water leakage detector.
● Optional built-in low-temperature component.
● Support upflow supply, top front supply and downflow supply, which can be flexibly selected according to the actual application requirements.
