RM Series Modular Online UPS 10-90kVA (380V/400V/415V)

•Rackdesign

Modular design, compatible with 19” standard rack cabinet, convenient to integratedwith servers

•Flexible configuration

The system can be configured to 1/1 and 3/1 without derating or hardware changing

•High power density

10/15KVA power module in 2 U height Saving great amount of space, easy for capacityexpansion

•Friendly interface

7” touch color LCD with graphic display, more information displayed for customereasier for customer to operate

•Integrated solution for data center

UPS can integrate with battery cabinet and PDU, offering excellent choice for datacenter

•Smart sleep function

System can intelligently shutdown some power modules to increase total load rate,achieving higher efficiency

•Intelligent charging management

The system intelligently control the whole process of the charging and discharging，effectivelyimprove she life time of the battery

•Self-agingmode

Energy internal circle technology, system can run with full load ,assuming less than10% energy

The standard 19”modular, scalable, hot-swappable, online double conversion UPS ranging from 10-90kVA, with its flexible configuration of 3/3, 3/1 and 1/1,compact structure, is the ideal choice for small and medium data center.
